ECOSYS M8124cidn
An A4/A3 colour Multi-Functional Product with 24 page per minute productivity (in A4). It’s ideal for small teams given the machine’s functionality, usability and compact size.
- Minimum installation and operation requirements.
- Easy to use full colour touch panel with wizard-style navigation.
- Long-life components provide exceptional reliability.
- HyPAS solution platform enables powerful customisations.
ECOSYS makes your office more sustainable and efficient
Kyocera solutions always work with the environment in mind, but the ECOSYS range do this more than any other product on the market.
Main Specifications
General
-
General
-
Paper Handling
-
Print
-
Copy
-
Scan
-
Fax
General type
Colour multifunctional for A3 format
Engine speed
Up to 24/12 pages A4/A3 per minute in colour and b/w
Warm-up time
Approx. 30 seconds or less
Power consumption
Sleep-mode: 0.5 W, Stand-by: 70 W, Copying/Printing: 550 W
Warranty
1-year warranty as standard (depending on the country). KYOCERA guarantees the drum and developer for 3 years or 300,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions.
Input capacity
100-sheet multi-purpose tray, 60–256 g/m²: A3, A4, A5, A6, B5, Ledger, Letter, Legal, Folio, Custom (98 x 148 to 297 x 432 mm) 500-sheet standard universal paper cassette, 60–256 g/m², A3, A4, A5, B5, Ledger, Letter, Legal, Folio
Max. input capacity with options
1,600 sheets
Duplex unit
Standard duplex unit: 60–256 g/m130
Max. output capacity
Max. 280 sheets; 250 sheets face-down (main tray), plus 30 sheets (standard Job Separator Tray)
Document processor
Standard reversing document processor: 50-sheet, Simplex scan 45–160 g/m², Duplex scan 50–120 g/m², A3, A4, A5, B5, Letter, Legal, Custom (140x182 to 297x432mm)
Processor
ARM Cortex-A9 Dual core1.2 GHz
Fonts
101 outline fonts (PCL 6, KPDL3, Windows Vista), 1 bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode PDF417 under PRESCRIBE (PCL and other barcodes available as options)
Features
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality
Applicable OS
All current Windows operating systems, Mac OS X Version 10.5 or higher, UNIX LINUX , as well as other operating systems on request.
Max. original size
A3/Ledger
Continuous copy
1 - 999
Zoom range
25 - 400 % in 1% steps
Preset magnification ratios
5 Reductions / 5 Enlargements
Image adjustments
Text, photo, text + photo, Map, Printed document
Digital copy features
Scan-once-copy-many, sort, 2in1, 4in1, job reserve, priority print, program, auto duplex copy, split copy, continuous scan, auto cassette change (PF-470 or PF-471 is required), copy density control, Prevent Bleed-Through, ID card copy, Skip blank page
Scan functionalities
Scan-to-Email, Scan-to-FTP, Scan-to-SMB, Scan-to-USB Host, Network TWAIN, WIA, WSD scan
Scan speed
b/w: 50 ipm (300 dpi, A4), Colour: 50 ipm (300 dpi, A4)
Scan features
Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip
Scan resolution
200, 300, 400, 600 dpi (256 greyscales per colour)
Max. scan size
A3/Ledger
File type
PDF, PDF/A, JPG, TIFF, XPS, PDF/A-1a/b, PDF/A-2a/b/u, Encrypted PDF High Compresson PDF
Original recognition
Text, photo, text + photo, light text, optimised for OCR
Compatibility
ITU-T Super G3
Modem speed
Max. 33.6 kbps
Scanning speed
2.0 second or less
Transmission speed
Max. 33.6 kbps
Scanning density
Normal: 8 dot/mm x 3.85 line/mm, Fine: 8 dot/mm x 7.7 line/mm, Superfine: 8 dot/mm x 15.4 line/mm, Ultrafine: 16 dot/mm x 15.4 line/mm, Halftone: 8 dot/mm x 7.7 line/mm
Max. original size
A3/Ledger
Fax features
Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast
Options and Consumables
Paper Handling Options
-
Paper Handling Options
-
Options
Fax System 13
Super G3 Fax, network fax
KYOmulticode SD 3
Contains all the functionalities of PCL Barcode Flash plus Unicode font “Andale Mono World Type“ which allows the user to print Asian fonts (Japanese, Korean, current and traditional Chinese)
PF-470
Paper feeder
